AFS Pure 700/900 V2 High Performance UHM Carbon Foils

AFS Pure 700/900 v2 High Performance Fuselink UHM Carbon Foils

The best design to win

AFS PURE foils are aimed at the advanced to expert rider looking for high performance.

Whether you're into serious competition or racing with your mates, boosting airs and tricks or you ride to carve and connect waves, then the Pure program is tailor made for you.

We have developed the Pure range with one goal : giving our world tour riders the best tools to win.

Camber profile
For this new version of our Pure 700 v2 and 900 v2, our team rider's favourite foils, we have pushed the aspect ratio above 9 (700 : 9.6 and 900 : 9.2) while slimming the fuselage profile overall to optimise the fuselink connection.

The result is a foil with less drag delivering amazing glide, speed and carving abilities.

Slashing effect
As we have increased the span, we've paid a lot of attention to the manoeuvrability on roll obviously but on yaw as well.

The foil is very playful and gives you the ability to be more aggressive in your transitions with the possibility to get a sliding/slashing effect.

Bombproof freestyle construction
As our riders take part in contests throughout the world, we wanted them to feel secure with the gear.

This is why our Pure range is a bombproof freestyle construction, meant to take the biggest landings and hold strong with a much reinforced connection between the front wing and the fuselage.

2 stab positions
As the foil is intended to be used as a very high performance all-rounder, 2 stab positions are included.

Use the forward position for more pitch reactivity and better efficiency in jumps, while the rear position will give you more control on the pitch in race and speed runs.


Pure 700 v2 and 900 v2 also perform incredibly well in the surf, their glide and pumping abilities will help you connect as many waves as your legs allow.

Wind range
Wind range ?75kg >75kg
10-20 knots Pure 700 Pure 900
>20 knots Pure 700 Pure 700

Pure 700 v2
Surface 700 cm2
Span 820 mm
Aspect Ratio 9.6
Max chord 112 mm
Max thickness 11.5 mm
Fuselage length 574 mm
Construction UHM Carbon

Pure 900 v2
Surface 900 cm2
Span 900 mm
Aspect Ratio 9.2
Max chord 137 mm
Max thickness 14.1 mm
Fuselage length 555 mm
Construction UHM Carbon


The Pure 700 v2 and 900 v2 will happily work with a wide range of AFS Stabilisers like the Performer Surf 160/190 stabs, SILK and SILK HA stabs, but we really recommend for most riders, the following with our PURE Foil range:

Advanced Pure Stab 145 or 150 with the Pure 700 and Pure 700 v2 Foil

Advanced Pure Stab HA135 with the Pure HA 800 Foil

Advanced Pure Stab 145 or 150 with the Pure 900 and Pure 900 v2 Foil

Advanced Pure Stab HA165 with the Pure HA 1100 Foil

With which mast?

PUREv2 foils can be fitted with all the masts in the AFS Fuselink range. However, we recommend the Fuselink UHM masts in order to exploit the full potential of the PURE Foil set.

Construction:

We use Pre-Preg Carbon/UHM (Ultra High Modulus) Carbon which allows us to optimise every section to give you an incredibly strong and stiff foil, with incredible performance and communication.


MADE IN FRANCE

We control the manufacturing process from A to Z of all our foils in our own factory, to ensure the best possible manufacturing quality. In addition, our exclusive pre-preg construction allows operators to no longer breathe toxic fumes emanating from the resin.

The pre-impregnated fibres are cut using a laser machine, then assembled in a mould and finally baked at the optimum pressure and temperature to obtain the desired shape and incredible strength to weight ratio only delivered by this sophisticated manufacturing process.

PACK

Complete with bags which allow it to be left mounted on the mast and stabiliser, or stored demounted.

Warranty

All AFS Advanced products come with a 3 year warranty, subject to our fair usage policy.
